Hardware

Static facts about the Lofi-12 XT hardware (own teardown + photos in photos/). Behavioral/firmware side: ../FINDINGS.md, bootloader.md.

Boards

PCB	Role
`405-VTOR-3852`	I/O board (jacks, MIDI, relays `HFD4/5`, USB-C area)
`405-VTOR-3849B`	Main board (`28-AUG-2023` rev on unit): SD slot, MCU, power, FFC to UI
`405-VTOR-3853`	Jack sub-board (`2/JUN/2022`)
core module (unmarked)	Compute: SoC + DDR + 2× SPI flash, board-to-board `CN200A/CN201A/CN203A/CN203B`

TI TMS320C6748 (TMS320 C6748EZW T / 13CP99W) — main SoC, ARM9 + C674x DSP.
EtronTech EM68C16CWQG-25H (B07DY15MSYA0051) — 1 Gbit DDR2.
2× Macronix MX25L12833F (MXIC MX 25L12833F M2I-10G), 16 MiB SPI NOR each, silkscreen IC300 (boot+app) / IC301 (data). Factory stickers cover the marking (C047/C949-style labels) — peel + photograph before any clip work.
ARTERY AT32F421K8T — USB/aux MCU, separate firmware (strings reference updateMCUSection/updateMCUBootSection; protocol not reversed).

Region	Use
`0xC2xxxxxx`	SD `.bin` application image (v1.5: code `C2B80C00`, strings `C2D84DE0`)
`0xC7074630–C70B0598`	SPI AIS bootloader image, entry `C70A28A0`
`0xC706F280`	Updater constant (file/scratch buffer area)
`0xC27C6282`	Updater DDR scratch; value reused as checksum seed

Flash VCC measures 3.3 V in-circuit — never apply 5 V (see RE-PROCESS.md §1).
Jack board silkscreen: A+7.5V / AGND / A-7.5V analog rails, DSU/AGNC.
Main-board silkscreen tables name UART1_RX1/TX1, SPI1_SCK/MOSI, SD_*, USB_DP/DN, key matrix (KS1–KS6, EN_1A–5B), TP1–TP5 — candidates for UART/JTAG mapping (continuity not yet traced; see uart-zoom.jpg).

Core module — SoC, DDR2 and both SPI flashes (bottom edge).

Both are Macronix MX25L12833F, 16 MiB. Pin-1 dots face down-left; note the IC300/IC301 silkscreen between the packages.

Close-up of the UART test-point area (unannotated).
